studioetrange/romvault

ROMVault is a ROM manager

]

This image is based on {LinuxServer.io](https://linuxserver.io) images system.

This image contains ROMVault and RVCMD binaries.

Supported Architectures

The architectures supported by this image are:

Architecture	Tag
x86-64	latest

See available tags here

• studioetrange/docker-romvault
• ghcr.io/studioetrange/docker-romvault

Usage

Here are some example snippets to help you get started creating a container.

docker-compose (recommended)

Compatible with docker-compose v2 schemas.

---
version: "2.1"
services:
  calibre:
    image: ghcr.io/studioetrange/docker-romvault
    container_name: romvault
    environment:
      - PUID=1000
      - PGID=1000
      - TZ=Europe/London
      - GUAC_USER=abc #optional
      - GUAC_PASS=900150983cd24fb0d6963f7d28e17f72 #optional
      - UMASK_SET=022 #optional
    volumes:
      - /path/to/data:/config
    ports:
      - 8080:8080
      - 3389:3389
    restart: unless-stopped

docker cli

docker run -d \
  --name=romvault \
  -e PUID=1000 \
  -e PGID=1000 \
  -e TZ=Europe/London \
  -e GUAC_USER=abc `#optional` \
  -e GUAC_PASS=900150983cd24fb0d6963f7d28e17f72 `#optional` \
  -e UMASK_SET=022 `#optional` \
  -p 8080:8080 \
  -p 3389:3389 \
  -v /path/to/data:/config \
  --restart unless-stopped \
  ghcr.io/studioetrange/docker-romvault

Parameters

Parameter	Function
-p 8080	Allows HTTP access to a web desktop gui (with Guacamole).
-p 3389	Allows RDP access to the desktop.
-e PUID=1000	for UserID - see below for explanation
-e PGID=1000	for GroupID - see below for explanation
-e TZ=Europe/London	Specify a timezone to use EG Europe/London.
-e GUAC_USER=abc	Username for the desktop gui.
-e GUAC_PASS=900150983cd24fb0d6963f7d28e17f72	Password's md5 hash for the calibre desktop gui.
-e UMASK_SET=022	for umask setting, default if left unset is 022.
-v /config	This is where the application stores its configuration, log and any files needing persistency.

Umask for running applications

For all of our images we provide the ability to override the default umask settings for services started within the containers using the optional -e UMASK=022 setting. Keep in mind umask is not chmod it subtracts from permissions based on it's value it does not add. Please read up here before asking for support.

User / Group Identifiers

When using volumes (-v flags) permissions issues can arise between the host OS and the container, we avoid this issue by allowing you to specify the user PUID and group PGID.

Ensure any volume directories on the host are owned by the same user you specify and any permissions issues will vanish like magic.

In this instance PUID=1000 and PGID=1000, to find yours use id user as below:

  $ id username
    uid=1000(dockeruser) gid=1000(dockergroup) groups=1000(dockergroup)



Application Setup

This image sets up the desktop app and makes its interface available via Guacamole server in the browser. The interface is available at http://your-ip:8080.

By default, there is no username or password set. Custom usernames and passwords can be set via optional docker environment variables. Keep in mind that the GUACPASS variable accepts the md5 hash of the desired password (the sample above is the hash for abc). The md5 hash can be generated by either of the following commands:

echo -n password | openssl md5

printf '%s' password | md5sum

Port 8081 is reserved for Calibre's built-in webserver, which can be enabled within the desktop app settings, and the internal port must be set to 8081 although it will then be available at the host mapped port for external access.

You can access advanced features of the Guacamole remote desktop using ctrl+alt+shift enabling you to use remote copy/paste and different languages.

Building locally

If you want to make local modifications to these images for development purposes or just to customize the logic:

git clone https://github.com/studioetrange/docker-romvault.git
cd docker-romvault
docker build \
  --no-cache \
  --pull \
  -t studioetrange/docker-romvault:latest .

If you want to pick a romvaul version use build args ROMVAULT_VERSION and RVCMD_VERSION and pick versions on https://www.romvault.com/

git clone https://github.com/studioetrange/docker-romvault.git
cd docker-romvault
docker build \
  --no-cache \
  --pull \
  --build-arg ROMVAULT_VERSION=3.4.4 \
  --build-arg RVCMD_VERSION=3.4.2 \
  -t studioetrange/docker-romvault:3.4.4 .

using makefile

make ROMVAULT_VERSION=latest RVCMD_VERSION=latest
